HORSEMAN DIGITAL SOLUTION

This is the light weight handheld view camera converter which offers pro digital back users a variety of technical movements of tilt/swing, rise/fall and lateral shift with using large format lenses. The vertical and horizontal shifts of rear standard will enable you to stitch the images for novel or panoramic effects.

The ultimate view camera fully equipped tilt/swing and rise/fall as well as lateral shift on both front and rear standards designed exclusively for high-end digital backs. The workflow of framing, focusing and image capture can be achieved by simply shifting the digital back with smooth movement. An interchangeable adapter plate system allows Hasselblad “V”, “H” and Mamiya 645 mounts to hold almost all the digital backs. A flexible bellows extension makes flange focal distance from minimum 33mm to maximum 360mm.

Super Wide Angle camera system with digital pro backs. The 23mm lens unit with a 36 x 48mm sensor gives you the same wide angle as a 17mm lens with the 35mm format. Distortion free wide angle images can be created with using quality lenses from Rodenstock and Schneider.

The lens series of HR Digaron-W with an image circle from 90 mm to 125 mm is the first choice for large sensors from 37x49 mm up to 36x56 mm or 40x54 mm and for technical cameras, if lateral shift and swing / tilt require large camera movements. For an optimum performance of the highest resolution sensors with up to 60 megapixels and a pixel pitch down to 6 µm, the optical design includes the thickness of the sensor glass plate.

The Rodenstock HR Digaron-S lenses with a 70mm image circle (80 mm for a focal lengths of 180 mm) for sensor sizes from 24x36 mm up to 33x44 mm provide excellent sharpness and brilliance even from open aperture (f/4 to f/5.6). For reduced camera movements they are also recommended for sensor sizes up to 37x49 mm and without any camera movements even for sensor sizes up to 36x56 mm or 40x54 mm.


Both lens series Apo-Sironar digital and Apo-Macro-Sironar digital provide large image circles and leave enough space for camera movements. These lenses are ideal for use with digital scan backs as well as with chip backs having larger formats or for being used in the macro-scan mode for larger formats by stitching multiple shots made with sliding back from one shot to the next. Resolving power is designed for a pixel pitch down to 9 µm. These lenses are the perfect solution for photographers who use both digital photography and roll film.

Operated entirely via digital electronics, the ISS-G3 boasts a timing precision ten times higher than that of mechanical systems. Fully digital aperture control permits fine adjustments in steps down to 1/6th or even 1/10th of a stop and ensures digitally controlled 1/125 seconds through a long 99 minutes and 59 seconds shutter speed. Lens data for almost all large format lenses available in the world today has been preprogrammed to guarantee the precise digital exposure settings.
